1 ton Commercial mini air cooled chiller
Air-cooled Commercial chiller do not need to connect the cooling tower, it's easy to install and move. Build with wheels, Cooling Capacity from 0.5 ton to 8 ton, Compressor adopt Rotor type or Scroll type, Brand can be optional, such as Gree, Panasonic, Copeland, Daikin. Oumal Commercial Chiller Price is very competitive, Wanrranty time of oumal chiller is 15 Months, If you are looking for commercial air cooled chiller, please feel free to contact me. Will quote you the as soon as possible.
Oumal brand mini air chiller features outstanding advantages as follows:
1. The controls of a portable air chiller are mic-computer controller.
2. Each portable air chiller unit using the US or Japan branded hermetic-scroll compressor featuring high cooling performance, low noise and low electricity consumption make a commercial chiller.
3. We have a full product lineup, the cooling capacity of portable air chiller from 0.5ton to 50ton and various configurations to fit your process applications.
4. The portable air chiller has a built-in large volume stainless steel reservoir with stainless steel water pump. also single or dual pumps for primary and secondary.
5. Air Cooled Condenser used in portable air chiller features: Heavy-duty construction with maximum heat transfer, Seamless copper tubes mechanically expanded into aluminum fins making permanent metal-to-metal contact, Direct drive propeller fan, low noise level
6.The evaporator of portable air chiller is using stainless steel plate type heat exchanger features high efficiency and long-lasting service time.
7. The portable air chiller has complete protection devices such as: Compressor overheating protection, high and low-pressure alarm, water level switch, water flow switch, and Dryer Filter/Moisture Indicator.
Our portable air chillers are widely used in industrial cooling processes such as: Plastic & rubber machinery, food and beverage processing, MRI machines, Laser industry, and printing…
As a professional portable air chiller supplier in China, Oumal has more high performance and convenience features into our portable air chillers.
Besides, we can also customize the portable air chiller specific to your demands.
Contact us to get a quick quote of your portable air chiller now.
small air chiller Products Information
●：Chiller cooling capacity 0.5 Ton to 10 Ton
●：Temperature control 5℃ to 35℃
●：Temperature stability ±0.5℃ to ±2℃
●：Large Copper Condensing Coil with Aluminum Fins
●：Built-in SS water tank and water pump
●：Schneider Electrical components & Mic-computer control panel
●：Easy installation and operation
●：Compact design with portable wheel
●：Low maintenance cost
Application of fan coil condenser small air Chiller
Mini Air cooled chiller is widely used in plastic industry, electrons, plating, chemical industry, ultrasonic wave cooling, printing and others. This kind of air cooled industrial chillers can precisely control the temperature requested during industrial processing, and also it greatly improved the production efficiency and quality, as well as reducing production time. OUMAL air cooled industrial chiller doesn’t require cooling tower, which is easy to install and move.
|
Model Item |
OMC-1.5A |
||
|
Cooling Capacity |
KW |
3.6 |
|
|
Kcal/h |
3096 |
||
|
Ton |
1 |
||
|
Btu/h |
12287 |
||
|
Input Power |
KW |
1.8 |
|
|
Power supply |
1PH-220V 50Hz |
||
|
Temperature Range |
℃ |
5-35 |
|
|
Refrigerant |
Type |
|
R22（R407C/R410A/R134A） |
|
Compressor |
Control Mode |
|
Capillary |
|
Type |
|
Piston Type / Scroll Type / Rotory type |
|
|
Power |
KW |
1.2 |
|
|
Chilled water |
Tank Volume |
L |
25 |
|
Tank Material |
|
SUS304 Stainless Steel |
|
|
Pipe Diameter |
inch |
1/2〃 |
|
|
Pump |
Lift |
m |
20 |
|
Power |
kw |
0.37 |
|
|
Evaporator |
Type |
|
Tank with coil（Shell and Tube） |
|
Chilled Water Flow |
m³/h |
0.6 |
|
|
Condenser |
Type |
|
High efficiency copper condensing coil with Aluminum+Spiral axial flow fan |
|
Cooling Water Flow |
m³/h |
1500 |
|
|
Dimension |
Length |
mm |
700 |
|
Width |
mm |
450 |
|
|
Height |
mm |
880 |
|
|
Weight |
KG |
80 | |
|
Safety Protection : Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection, reversed and lacking phase protection, exhaust overheating protection. |
|||
Package & Shipping
FAQ
Q1: Could you help us to recommend the model for our project?
A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:
1)Cooling capacity;
2)chilled water inlet and outlet temperature
3)chilled water flow
4) Refrigerant;
5) Ambient temperature;
6)Voltage;
7) Be used for what industry?
8)Any other special requirements
Q2: How to ensure your product with good quality?
A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.
also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users
Q3: What's the warranty?
A3: 15 months warranty for free if confirmed by both side damage in the quality reason.
Q4: What’s your payment term?
A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.
Q5: Are you a manufacturer?
A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance .
The control box design make the unit safety and stably.
Q6: How can i Place an order ?
A6: Click Below to fill the table or Call 0086 15112554736
