20 HP Air cooled chiller for Plastic Industry

Industrial Air Cooled Scroll Chiller OMC-20A, No need to connect cooling tower, Easy installation, easy moving.
  • Item NO.:

    OMC-20A
  • Payment:

    T/T, L/C, WEST UNION
  • Product Origin:

    CHINA
  • Color:

    CUSTOMIZE
  • Shipping Port:

    SHENZHEN
  • Lead Time:

    10-15 Working days
  • Order(MOQ):

    1
  • Goods Stock:

    20
  • Product Detail

20 HP Air Cooled Chiller for Plastic Industry



Air cooled chiller is short for air chiller, sometimes also called air cooled packaged chiller or portable air chiller and air cooled water chiller.

Air cooled chiller from OUMAL consists of a scroll compressor, air cooled condenser, built-in water pump and water tank to make a complete compressed refrigeration and water cooling system.

Air cooled chiller is widely used in plastic industry, electrons, plating, chemical industry, ultrasonic wave cooling, printing and others. This kind of air cooled industrial chillers can precisely control the temperature requested during industrial processing, and also it greatly improved the production efficiency and quality, as well as reducing production time. OUMAL air cooled industrial chiller doesn’t require cooling tower, which is easy to install and move.


OUMAL industrial air chiller system is your best partner for industry process cooling and it features easy operation, reasonable design, high quality, high efficiency, energy-saving and environmental. Further more, both air cooled screw type and air cooled scroll type are available at any cooling capacity.

Normally a wide range of standard air cooled chiller can be found in following specification tables, but standard chiller systems may not always fit your unique cooling requirements. So our specialist sales can suggest units that are customized to meet your unique needs.


As a professional air cooled chiller manufacturer, OUMAL has exported many air cooled chillers to the Philippines, Australia, New Zealand, Malaysia, Singapore, Indonesia, Chile, Mexico, Costa Rica, Brazil, Argentina, Colombia, South Africa, Nigeria, Saudi Arabia, Dubai, Spain, Italy, etc.

If you are looking for a high-quality air-cooled chiller manufacturer, please contact OUMAL sales for the best price quotation.



Air-Cooled Industrial Chiller Products Information


●:Chiller cooling capacity 1 Ton to 40 Ton

●:Temperature control 5℃ to 35℃

●:Temperature stability ±0.5℃ to ±2℃

●:Large Copper Condensing Coil with Aluminum Fins

●:Built-in SS water tank and water pump

●:Shell & tube or SS Plate Heat Exchanger for optional

●:Schneider Electrical components & Mic-computer control panel

●:Easy installation and energy saving

●:All models and cooling capacity are available

Air-cooled water chiller


Application of Air Cooled Chiller


As Air Cooled Chiller No Need to Use Cooling Tower, It's easy installation and moving, Air Cooled Chiller is widely used in plastic industry: such as injection molding machines, extruding machines, Stretch film machines, bottle blowing machines; electroplate industry, Medical chillers, laboratory chillers, Electronics industry, textile industry.....

Air cooled chiller application


Products Specification


  Model      Item

OMC-20A

Cooling Capacity

KW

54

Kcal/h

46440

Ton

15.4

Btu/h

184300

Input Power

KW

18

Power supply

3PH-380V  50Hz

Temperature Range

5-35

Refrigerant

Type


R22(R407C/R410A/R134A)

Compressor

Control Mode


Expansion Valve

Type


Piston Type / Scroll Type

Power

KW

15

Chilled water

Tank Volume

L

400

Tank Material


SUS304 Stainless Steel

Pipe Diameter

Inch

2〃

Pump

Lift

m

20

Power

kw

2.2

Evaporator

Type


Tank with coil(Shell and Tube)

Chilled Water Flow

m³/h

9.3

Condenser

Type


High efficiency copper condensing coil with Aluminum + Spiral axial flow fan

Cooling Water Flow

m³/h

20000

Dimension

Length

mm

2100

Width

mm

850

Height

mm

1600

Weight

KG

850

Safety Protection: Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection, reversed and lacking phase protection, exhaust overheating protection.


Packing & Shipping


FAQ


Q1: Could you help us to recommend the model for our project?

A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:

1)Cooling capacity;

2)chilled water inlet and outlet temperature

3)chilled water flow

4) Refrigerant;

5) Ambient temperature;

6)Voltage;

7) Be used for what industry?

8)Any other special requirements?



Q2: How to ensure your product with good quality?

A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.

also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users



Q3: What's the warranty?

A3: 15 months warranty for free if confirmed by both side damage in the quality reason.



Q4: What’s your payment term?

A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.



Q5: Are you a manufacturer?

A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance .

The control box design make the unit safety and stably.



Q6: How can i Place an order ?

A6: Click Below to fill the table or Call 0086 15112554736
