0.5 ton fan coil condenser small air chiller

0.5 ton fan coil condenser small air chiller OMC-1A, Fan cooling type & coil condenser without connect to the cooling tower, Easy installation.
  • Item NO.:

    OMC-1A
  • Payment:

    T/T, L/C, WEST UNION
  • Product Origin:

    CHINA
  • Color:

    CUSTOMIZE
  • Shipping Port:

    SHENZHEN
  • Lead Time:

    7-10 Working days
  • Order(MOQ):

    1
  • Goods Stock:

    10
  • Product Detail

0.5 ton fan coil condenser small air chiller


Air-cooled refrigeration units are also called air-cooled chillers, and use High efficiency copper condensing coil with Aluminum + Spiral axial flow fan for heat dissipation. The air-cooled chiller is an industrial cooling equipment equipped with a compression refrigeration circuit, which uses air as the cooling medium of the condenser and water as the refrigerant. The air-cooled chiller mainly includes a compressor, a condenser, an evaporator, The four main components of the throttling device. Because it has the advantages of easy installation and no cooling water system, it is widely used in industrial temperature control and air conditioning equipment. Fan coil condenser type Small air chiller is a small size and small cooling capacity of air cooled chiller, it do not need much space and easy to move and install.



The working principle of air-cooled chillers:

During the operation of the air-cooled chiller, the refrigerant absorbs the heat of the cooled object and vaporizes in the evaporator. The compressor continuously extracts the produced gas from the evaporator and compresses it into high-temperature, high-pressure steam, refrigerant vapor After being sent to the condenser, it exchanges heat with the air. After the heat is released, it is condensed into a liquid. After the pressure is reduced by the throttling mechanism, it enters the evaporator, vaporizes again, absorbs the heat of the cooled object, and circulates again and again.



Features of air-cooled chillers:

(1) Due to the difference in heat transfer temperature, the condensing temperature of the air-cooled chiller is higher than that of the water-cooled under the same outdoor environmental conditions. Therefore, the power consumption of the air-cooled chiller is the same when the cooling capacity is the same. The amount will be higher. In terms of energy efficiency, the cooling capacity of water-cooled chillers is usually 300~500Kcal/h higher than that of air-cooled chillers.



(2) The air-cooled chiller avoids the problems of condenser fouling and water pipe blockage in areas with poor water quality, and saves water resources. However, the heat exchange efficiency of the finned condenser used is greatly affected by the accumulation of ash and dirt. A dust filter must be installed before the heat dissipation fin tube, and it needs to be cleaned regularly.



(3) Compared with water-cooled chillers, air-cooled chillers use finned condensers, which directly use fans to force air flow to take away the heat of the refrigerant, and other auxiliary equipment is not required, which can save you Cooling tower, cooling water pump and cooling piping system. Therefore, it has certain advantages in installation, especially small chillers that do not require much cooling capacity, which are more convenient when moving!



Oumal brand portable air chiller features outstanding advantages as follows:



1. The controls of a portable air chiller are mic-computer controller.

2. Each portable air chiller unit using the US or Japan branded hermetic-scroll compressor featuring high cooling performance, low noise and low electricity consumption make a commercial chiller.

3. We have a full product lineup, the cooling capacity of portable air chiller from 0.5ton to 50ton and various configurations to fit your process applications.

4. The portable air chiller has a built-in large volume stainless steel reservoir with stainless steel water pump. also single or dual pumps for primary and secondary.

5. Air Cooled Condenser used in portable air chiller features: Heavy-duty construction with maximum heat transfer, Seamless copper tubes mechanically expanded into aluminum fins making permanent metal-to-metal contact, Direct drive propeller fan, low noise level

6.The evaporator of portable air chiller is using stainless steel plate type heat exchanger features high efficiency and long-lasting service time.

7. The portable air chiller has complete protection devices such as: Compressor overheating protection, high and low-pressure alarm, water level switch, water flow switch, and Dryer Filter/Moisture Indicator.



Our portable air chillers are widely used in industrial cooling processes such as: Plastic & rubber machinery, food and beverage processing, MRI machines, Laser industry, and printing…


As a professional portable air chiller supplier in China, Oumal has more high performance and convenience features into our portable air chillers.

Besides, we can also customize the portable air chiller specific to your demands.

Contact us to get a quick quote of your portable air chiller now.


small air chiller Products Information


●:Chiller cooling capacity 0.5 Ton to 10 Ton

●:Temperature control 5℃ to 35℃

●:Temperature stability ±0.5℃ to ±2℃

●:Large Copper Condensing Coil with Aluminum Fins

●:Built-in SS water tank and water pump

●:Schneider Electrical components & Mic-computer control panel

●:Easy installation and operation

●:Compact design with portable wheel

●:Low maintenance cost


Application of fan coil condenser small air Chiller



Portable Air cooled chiller is widely used in plastic industry, electrons, plating, chemical industry, ultrasonic wave cooling, printing and others. This kind of air cooled industrial chillers can precisely control the temperature   requested during industrial processing, and also it greatly improved the production efficiency and quality, as well as reducing production time. OUMAL air cooled industrial chiller doesn’t require cooling tower, which is easy to install and move.


air chiller application

Products Specification


 Model     Item

OMC-1A

Cooling Capacity

KW

2.7

Kcal/h

2322

Ton

0.8

Btu/h

9215

Input Power

KW

1.4

Power supply

1PH-220V  50Hz

Temperature Range

5-35

Refrigerant

Type


R22(R407C/R410A/R134A)

Compressor

Control Mode


Capillary

Type


Piston Type / Scroll Type

Power

KW

0.75

Chilled water

Tank Volume

L

25

Tank Material


SUS304 Stainless Steel

Pipe Diameter

inch

1/2〃

Pump

Lift

m

20

Power

kw

0.37

Evaporator

Type


Tank with coil(Shell and Tube)

Chilled Water Flow

m³/h

0.5

Condenser

Type


High efficiency copper condensing coil with Aluminum+Spiral axial flow fan

Cooling Water Flow

m³/h

1000

Dimension

Length

mm

680

Width

mm

420

Height

mm

850

Weight

KG

73

Safety Protection : Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection, reversed and lacking phase protection, exhaust overheating protection.


Package & Shipping



FAQ


Q1: Could you help us to recommend the model for our project?

A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:

1)Cooling capacity;

2)chilled water inlet and outlet temperature

3)chilled water flow

4) Refrigerant;

5) Ambient temperature;

6)Voltage;

7) Be used for what industry?

8)Any other special requirements



Q2: How to ensure your product with good quality?

A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.

also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users



Q3: What's the warranty?

A3: 15 months warranty for free if confirmed by both side damage in the quality reason.



Q4: What’s your payment term?

A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.



Q5: Are you a manufacturer?

A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance .

The control box design make the unit safety and stably.



Q6: How can i Place an order ?

A6: Click Below to fill the table or Call 0086 15112554736
