200kw anti-corrosion low temperature water cooled screw chiller with -12C outlet water temperature

The 12C outlet water temperature chiller use high quality Nickel-nickel copper tube + 316 stainless steel shell and tube evaporator. Build in 2 sets of Hanbell semi-hermetic screw compressors. Controller build in Siemens PLC + WeiView HMI. Intelligent temperature control, easy to operate.

  • Item NO.:

    OMC-140WDL
  • Payment:

    T/T, L/C, WEST UNION
  • Product Origin:

    CHINA
  • Color:

    CUSTOMIZE
  • Shipping Port:

    SHENZHEN
  • Lead Time:

    20-30 Working days
  • Order(MOQ):

    1
  • Cooling Capacity:

    200kw
  • Chilled Water Flow:

    34.4 m3/h
  • Compressor type:

    semi-hermetic screw
  • Temperature Range:

    -12C
  • Power Supply:

    3-380V-50Hz
  • Refrigerant:

    R22
  • Warranty:

    15 months
  • Product Detail

200kw anti-corrosion low temperature water cooled screw chiller with -12C outlet water temperature

A 200KW low temperature calcium nitrite calcium nitrate chiller system with an anti-corrosion evaporator is designed for cooling applications that require a temperature as low as -12°C. The chiller utilizes a screw compressor refrigeration system, which is known for its efficiency and reliability in industrial cooling systems.

The chiller system is specifically designed to handle the cooling requirements of calcium nitrite and calcium nitrate processes. These processes often require a low-temperature environment to maintain the stability and quality of the products.

The evaporator of the chiller is made of nickel white copper, which is chosen for its anti-corrosion properties. This is important because the chiller operates at low temperatures and comes into contact with the calcium nitrite and calcium nitrate solutions, which can be corrosive.

The chiller system is capable of maintaining a stable and precise temperature control, ensuring optimal performance and product quality throughout the cooling process. It is also designed for energy efficiency, reducing operational costs in industrial applications.

Overall, the chiller system provides a reliable and efficient solution for low-temperature cooling in processes involving calcium nitrite and calcium nitrate, with special attention to anti-corrosion measures to ensure long-term durability and performance.


 Low Temperature Chiller Products Information


●:Temperature control -35℃ to 5℃

●:SS brazed Plate Heat Exchanger or 316 SS shell and tube evaporator

●:Glycol mixture or salt marine suitable

●:Screw or piston compressor available

●:Safety protection covered low-temperature chiller

●:Schneider electrical components

●:PLC / Touch screen/Mic-computer control panel.


-12 °C outlet low temperature screw chiller Product Features

Cooling Capacity: The chiller is designed to provide sufficient cooling capacity to achieve and maintain a temperature of -12°C effectively. lower temperature can be reached according to the Antifreeze concentration.

Screw Compressor: The chiller is equipped with double screw compressors, which is known for its efficient and reliable operation even at low temperatures.

High Energy Efficiency: The chiller is designed to optimize energy consumption and ensure cost-effective cooling operations.

Precise Temperature Control: The chiller offers precise temperature control, allowing for tight temperature regulation at -12°C, which is crucial for applications that require precise temperature conditions.

Anti-corrosion Features: The chiller might have anti-corrosion measures implemented, such as a nickel white copper evaporator or coatings, to protect the system from damage caused by the cooling medium and ensure its longevity. The evaporator of this chiller use Nickel-white copper tube + 316 stainless steel shell.

Robust Construction: The chiller is constructed with durable materials and components to withstand the low-temperature environment and ensure long-term reliability.

Safety Features: The chiller may include safety features such as temperature sensors, pressure alarms, and safety controls to prevent any potential risks or malfunctions.

Easy Maintenance: The chiller might have a user-friendly design with easy access to components, making maintenance and servicing more convenient.

Application Versatility: The -12°C low temperature screw chiller can be utilized in various industries and applications, such as chemical processing, industrial cooling, food processing, and more.

It's important to note that the specific features and specifications of a -12°C low temperature screw chiller may vary depending on the manufacturer and the intended application.
low temperature screw chiller

-12C water cooled screw chiller


Low Temperature Chiller Application


Air Conditioning Project
Air-conditioning engineering is a broad field of refrigeration technology application. Optical instruments, precision measuring tools, textiles and other production workshops and computer rooms all require varying degrees of control of the temperature, humidity, and cleanliness of the environment; public buildings such as stadiums, conference halls, hotels, etc. need comfortable air-conditioning system.
Food engineering
Perishable food must maintain a stable low temperature environment during the entire circulation process from procurement or fishing, processing, storage, transportation to sales, in order to extend and improve the quality, economic life and value of food. This requires a variety of refrigeration facilities, such as cold processing equipment, refrigerated warehouses, refrigerated transport vehicles or ships, refrigerated vending counters, and so on.
Machinery and Electronics Industry
The oil pressure system of the precision machine tool uses refrigeration to control the oil temperature, which can stabilize the rigidity of the oil film and enable the machine tool to work normally. Low-temperature treatment of steel can improve the performance of the steel, increase the hardness and strength of the steel, and prolong the service life of the workpiece. Electronic equipment such as multiple communications, radars, and satellite ground stations also need to work at low temperatures.
Medical and health services
Plasma, vaccines and some special medicines need to be stored at low temperatures. Low temperature anesthesia, low temperature surgery, and cold compresses for high fever patients also require refrigeration technology.
Defense Industry and Modern Science
The performance of conventional weapons such as engines, automobiles, tanks, and artillery used in high-cold areas requires environmental simulation tests. Rockets and spacecraft also need to be tested under simulated high-altitude conditions, all of which require artificial refrigeration technology. Artificial rainfall also requires cooling. The application of screw chiller refrigeration technology is very extensive. With the development of the national economy, the progress of science and technology, and the continuous improvement of people's living standards, the development and application of refrigeration technology will move to new areas.

Screw type chiller

Products Specification


    Item                                     Model OMC-140WDL
Nominal cooling capacity Temp -10℃ 240
-20℃ 159
-30℃ 96.6
Input Power KW 97.6
Power Supply 3PH-380V/415V 50HZ(220V/440V  60HZ))
Refrigerant Type R22 (R404A)
Control Mode Expansion Valve
Compressor Type Semi-Hermetic Screw
Power KW  97.6
Start-up Mode Y-
Capacity Control 0-25-50-75-100 (0-33-66-100)
Evaporator Type  Temp Shell and Tube
Chilled water flow -10℃ m3/h 41.28
-20℃ 27.3
-30℃ 16.6
Pipe Diameter Inch 4”
Condenser  Type Shell and Tube
Cooling water flow m3/h 58
Pipe Diameter Inch 3" x 2
Dimension Length mm 3500
Width mm 1300
Height mm 2000
Net Weight kg 3160
Running Weight kg 3400
Safety Protection: Compressor over temperature protection, over load protection, high and low pressure protection, anti-freezing protection, reversed and lacking phase protection, fusible blug, flow switch

Package and Shipping



FAQ

Q1: Could you help us to recommend the model for our project?

A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:

1)Cooling capacity;

2)chilled water inlet and outlet temperature

3)chilled water flow

4) Refrigerant;

5) Ambient temperature;

6)Voltage;

7) Be used for what industry?

8)Any other special requirements?


Q2: How to ensure your product with good quality?

A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.

also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users


Q3: What's the warranty?

A3: 15 months warranty for free if confirmed by both side damage in the quality reason.


Q4: Whats your payment term?

A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.


Q5: Are you a manufacturer?

A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance.

The control box design make the unit safety and stably.


Q6: How can i Place an order

A6: Click Below to fill the table or Call 0086 15112554736
