15 HP Open type scroll water chiller unit
Open type scroll water chiller unit is one kind of water-cooled chiller, As the open type water to water cooled chiller without pump and water tank, it is smaller than box type water cooled chiller. And the cost is lower than the Packaged water cooled chiller and air cooled chiller. It's a commercial water chiller.
As a professional water chiller unit manufacturer, OUMAL has exported many water cooled chiller units to the Philippines, Australia, New Zealand, Malaysia, Singapore, Indonesia, Chile, Mexico, Costa Rica, Brazil, Argentina, Colombia, South Africa, Nigeria, Saudi Arabia, Dubai, Spain, Italy, etc.
If you are looking for a high-quality sea water cooled chiller or brine chiller manufacturer, please contact OUMAL sales for the best price quotation.
Water Chiller Units Products Information
●：Chiller cooling capacity 3Ton to 80 Ton
●：Temperature control 5℃ to 35℃
●：Temperature stability ±0.5℃ to ±2℃
●：Shell and tube condenser and evaporator
●：Hermetic scroll compressor: Copeland, Panasonic, Daikin, Danfoss optional
●：Schneider Electrical components & Mic-computer control panel
●：Low cost and energy saving water chiller units
Products Specification
| Model Item | OMC-15W | ||
| Cooling Capacity | KW | 45 | |
| Kcal/h | 38700 | ||
| Ton | 12.8 | ||
| Btu/h | 153583 | ||
| Input power | KW | 11.25 | |
| Power supply | 3 PH-380V 50Hz | ||
| Temperature Range | ℃ |
-30℃-5℃ |
|
| Refrigerant | Type | R22（R407C/R410A/R134A） | |
| Compressor | Control Mode | Expansion Valve | |
| Type | Scroll type / Piston Type/ Screw Type | ||
| Power | KW | 11.25 | |
| Evaporator | Type | 316 Stainless steeel Shell and tube | |
| Chilled water flow | m³/h | 7.7 | |
| Condenser | Type | 316 Stainless steel Shell and tube | |
| Cooling water flow | m³/h | 9.6 | |
| Dimension | Length | mm | 1250 |
| Width | mm | 780 | |
| Height | mm | 1150 | |
| Weight | KG | 650 | |
| Safety Protection: Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection,reversed and lacking phase protection, exhaust overheating protection. | |||
Packing & Shipping
FAQ
Q1:Could you help us to recommend the model for our project?
A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:
1)Cooling capacity;
2)chilled water inlet and outlet temperature
3)chilled water flow
4) Refrigerant;
5) Ambient temperature;
6)Voltage;
7) Be used for what industry?
8)Any other special requirements?
Q2:How to ensure your product with good quality?
A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.
also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users
Q3:What's the warranty?
A3: 15 months warranty for free if confirmed by both side damage in the quality reason.
Q4:What’s your payment term?
A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.
Q5:Are you a manufacturer?
A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance .
The control box design make the unit safety and stably.
Q6:How can i Place an order ?
A6: Click Below to fill the table or Call 0086 15112554736
