Scroll compressor water cooled chiller open type

Scroll compressor water cooled chiller open type OMC-20W. Build in 3 sets scroll compressors, Without housing, lower cost.
  • Item NO.:

    OMC-20W
  • Payment:

    T/T, L/C, WEST UNION
  • Product Origin:

    CHINA
  • Color:

    CUSTOMIZE
  • Shipping Port:

    SHENZHEN
  • Lead Time:

    20-30 Working days
  • Order(MOQ):

    1
  • Goods Stock:

    20
  • Product Detail

Scroll compressor water cooled chiller open type


Open type scroll water chiller unit is one kind of water-cooled chiller, it including the housing case so called open type water cooled chiller. The 20 HP water cooled chiller open type include the compressor, shell and tube condenser and shell and tube evaporator, Electric box. Not build the water pump and water tank, that made the chiller cost lower. So the water cooled chiller price is competitive.


As a professional water-cooled chiller supplier in China, OUMAL has exported many water cooled chiller machines to the Philippines, Australia, New Zealand, Malaysia, Singapore, Indonesia, Chile, Mexico, Costa Rica, Brazil, Argentina, Colombia, South Africa, Nigeria, Saudi Arabia, Dubai, Spain, Italy, etc.

If you are looking for a high-quality open  type water cooled chiller  or scroll compressor water chiller manufacturer, please contact OUMAL sales for the best price quotation.



Open type water cooled chiller Products Information


1. Product Name: scroll compressor water cooled chiller open type
2. Cooling capacity: 60kw
3. Output temp. :-5C/0C/7C
4. Power supply: 220V, 380-415V, 440V-460V, 50Hz or 60Hz;
5. Color: customized
6. Refrigerant: R22/R407C/R134a/R410a/R404a
7. Compressor: Hermetic scroll type
8. Evaporator: High efficiency copper tube shell and tube
9. Condenser: High efficiency copper tube shell and tube
10. Protection System: Compressor overheat protection, high/low pressure protection, phase missing/sequence protection, flow rate protection, anti-frozen protection.


Water chiller main parts


15 Ton water cooled chiller Products Specification


           Model   Item OMC-20W
Cooling Capacity KW 60
Kcal/h 51600
Ton 17
Btu/h 204778
Input power  KW 15
Power supply 3 PH-380V  50Hz
Temperature Range  5℃-35℃
Refrigerant Type R22(R407C/R410A/R134A)
Compressor Control Mode Expansion Valve
Type Scroll type / Piston Type/ Screw Type
Power KW 15
Evaporator Type  Steeel Shell and tube
Chilled water flow m³/h 10.3
Condenser Type 316 Stainless steel Shell and tube
Cooling water flow m³/h 12.9
Dimension Length mm 1350
Width mm 800
Height mm 1150
Weight KG 720
Safety Protection: Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection,reversed and lacking phase protection, exhaust overheating protection.


20HP Water cooled chiller open type Application


Open type water cooled Chiller used in many different industries:

Food and Beverages – Microbreweries, confectionary, bakeries, distilleries, wineries, bottling, carbonation, vegetable, meat and fish processing, etc.

Pharma and chemical – Jacketed vessels cooling, condenser cooling, PUF mixers, Laboratories applications, x ray spectrometers, paint cooling, packing machine, anodizing, plating, liquid nitrogen plant, etc

Other industries- plastic industry, electronics industry, electroplating industry, machinery industry, construction industry, laser industry, ultrasonic/ultrasound industry, numerical control processing industry, ship manufacturing industry, steel and iron manufacturing industry, discharge industry, shoe making industry, leather dry cleaning industry etc.




Packing & Shipping


Oumal Chiller use plywood package for overseas orders, shipping by bulk cargo or containers. Standard machines have stock can delivery when the payment recieved. For customized chiller or not standard power supply the delivery would be 15-30 working days according to different requirements.


mairine chiller cooling system deliver time


FAQ


Q1:Could you help us to recommend the model for our project?

A1: Yes, we have engineer to check the details and make the scheme for you. Based on the following:

1)Cooling capacity;

2)chilled water inlet and outlet temperature

3)chilled water flow

4) Refrigerant;

5) Ambient temperature;

6)Voltage;

7) Be used for what industry?

8)Any other special requirements?



Q2:How to ensure your product with good quality?

A2: All our products with CE certificate. And use the well-know brand accessories, such as copeland, danfoss,Hanbell, Bitzer compressor Emerson expansion Valve, Siemens controller.

also can be customized. All OUMAL Chillers are factory tested under load conditions to ensure good quality and easy installation for users



Q3:What's the warranty?

A3: 15 months warranty for free if confirmed by both side damage in the quality reason.



Q4:What’s your payment term?

A4: We accept T/T, LC, Western Union, etc. Normally, 30% deposit for production, 70% balance before shipment.



Q5:Are you a manufacturer?

A5: Yes, we have more than 15 years in water chiller business. Also have patent on the water chiller appearance .

The control box design make the unit safety and stably.



Q6:How can i Place an order ?

A6: Click Below to fill the table or Call 0086 15112554736
